Eaton VR+ Series User Manual

11
Instruction Book IB182923EN September 2018 www.eaton.com
AMH-4.76-VR
+
VR-Series
+
Replacement Circuit Breaker
Figure 3.4. Rear External View of AMH-4.76-VR
+
(AMH-4.76-VR
+
250-1200A Shown)
Rear External View
1 Shutter Actuator 4 SURE CLOSE Spring 7 Secondary Disconnect
2 Primary Disconnect 5 Guide Rail 8 Ground Contact
3 Racking Screw 6 Racking Access Door Interlock
1
2
3
4
5
6
7
8

Eaton VR+ Series Specifications

General

Trip Type	Thermal-magnetic
Voltage	120/240V
Number of Poles	1, 2
Standards	UL 489
Terminal Type	Screw
