- 28 -
EBA 550 • EBA 550 LT
A
B
• Blade and cutting stick replacement •
Remove remaining two screws (A).
Simultaneously slightly loosen both screws (B)
and remove blade with blade changing tool.
Weight of blade approx. 5 kg.
Place the blade into the blade carrier and
screw it into place.
