- 30 -
EBA 550 • EBA 550 LT
AB
C
E
D
E
D
A
B
• Blade and cutting stick replacement •
... and tighten with screws (B) in upper
position.
Blade must be in the upper position.
Mount the blade with the blade changing
tool (A) ...
Take the exchange blade carefully out of the
blade box and screw it to the blade changing
tool (D).
• Check, if when using the upper threads (B),
the blade (E) is protected.
• The blade is not protected Use the lower
thread (C) for fixing. The screws (A) may not
exceed at the rear side of the blade.
Danger!
Blade (E) must be protected.
