EBA 550 - Page 35

- 34 -
EBA 550 • EBA 550 LT
2.
3.
4.
5.
• Blade and cutting stick replacement •
Tighten the remaining 3 screws beginning
from the left.
Tighten the screw which is visible at the right.
Pull out blade locking key
 blade moves to the top.
