Section 2: System Specifications
2.1 System Utilities Requirements
Closed Loop System Full Load Amps:
Overall Full Load Amps for GRS and CLS:
Make-Up Water connection:
0.5” hose barb connection
Heat Exchanger inlet/outlet connection:
0.75” hose barb connection
2.2 System Components
Tank
General Dimension: 66" l x 36" w x 62" h
Tank Dimension: 30" l x 36" w x 30" h
Clean Tank Capacity: 50 US GAL
Dirty Tank Capacity: 100 US GALLONS
Max Tank Capacity: 150 US GALLONS
Bag Vessel (Vessel #1) – SLBV-0833-BC
Construction: 304 Passivated Stainless Steel
Bag Requirement: This unit accepts one (1) Filter Bag, extra fine extended
area Pre-Filter
Rim Gasket: Buna-nitrile
Media Requirement: CLS-1-G2PS-EA
Hurricane Vessel (Vessel #2) – HRF-LP
Construction: 316 Passivated Stainless Steel
Recommended Flow Rate: 30 GPM
Service Height Clearance: 62”
Filter Cartridge: This unit accepts one (1) 0.35 micron-rated Pleated
Polyester-Plus Filter Cartridge
Rim Gasket: E.P.D.M.
Media Requirement: HR-930-Q.35
D.I. Vessel (Vessel #3) – DI-1
Construction: 316 Passivated Stainless Steel
Capacity: One cubic foot of Water-jet Resin in a Poly Sateen Bag
(recyclable)
Rim Gasket: Buna-nitrile
Media Requirement: CLSR-100-PKG
Final Filter Vessel (Vessel #4 x2) – (HSL-10-0.50-WCP)
Quantity: 2 Separate Cartridges
Construction: Polypropylene
Flow Rate: 10 GPM
Filter Cartridge: This unit accepts one (1) 0.35 micron-rated Pleated
Filter Cartridge
Rim Gasket: E.P.D.M.
Media Requirement: CLS-801-Q.35 / CLS-801-0.2
