Section 2: System Specifications
System Pump – B82418
Closed-coupled, end suction, single-stage Centrifugal Pump.
Pumps water from Filtration System’s dirty tank through system vessels.
Motor: 460vac/3φ/60Hz
Horsepower: 1 HP
Speed: 3450 R.P.M.
Enclosure: T.E.F.C.
Full Load Amp @ 460vac: 2.0 Amps
Temperature: 212ºf maximum operating temp
Impeller: 5”diameter AISI 316 Stainless Steel
High-Pressure Feed Pump – TC40S340
Direct-coupled, self-priming, multi-stage Centrifugal Pump.
Delivers water from the Filtration System’s clean holding tank to customer’s machine tool.
Motor: 460vac/3φ/60Hz
Horsepower: 1.15 HP
Speed: 3300 R.P.M.
Enclosure: T.E.F.C.
Full Load Amp: 2.5 Amps
Impeller: multistage
Electrical Panel
Custom enclosure that controls both the Garnet Removal System and the closed loop system.
System Pump starter module: PKZMO Thermal Overload
Thermal overload set point @ 460vac: 2.0 (FLA of motor)
Feed Pump starter module: PKZMO Thermal Overload
Thermal overload set point @ 460vac: 2.5 (FLA of motor)
Total Dissolved Solids Meter – CIC-152-4
Digital monitor/controller.
Dual set point is internal to discourage unauthorized adjustments. If the conductivity signal becomes
greater than the conductivity set point at the solenoid valve will open allowing water to pass through
the D.I. Vessel. The conductivity probe is located inside the clean tank.
Range: 0-500 PPM
Conductivity Set Point A: 40 PPM
Change Resin-Flashing Beacon: 100 PPM
Contact Rating: SPDT 10 Amp @ 250vac, 30vdc.
