TECHNICAL PARAMETERS
The Heat Recovery System is categorized as a Class II product.
The protection level is IPX4.
The Heat Recovery System is projected for indoors installation. Working temperature is included between -30°C
and 50°C with maximum relative humidity of 80%.
The design of the Heat Recovery System is in continuous evolution, therefore, some models may differ from
those described in this manual.
DIMENSIONS, MM
- EBERG REQU / REQU+ / REQU R+ 160
- EBERG REQU / REQU+ / REQU R+ 100
EBERG REQU
Speed 1 2 3 4 5
Voltage at 50Hz 220-240Vac 220-240Vac X X X
Power Ø160 [W] 4,9 8,9 X X X
Power Ø100 [W] 3,9 7,9 X X X
Flow rate Ø160 [m³/h] 30 60 X X X
Flow rate Ø100 [m³/h] 15 30 X X X
Noise at 3 m Ø160 [dB] 13 23 X X X
Noise at 3 m Ø100 [dB] 19 29 X X X
Max Efficency 93% 93% X X X
EBERG REQU+
Speed 1 2 3 4 5
Voltage at 50Hz 220-240Vac 220-240Vac 220-240Vac X X
Power Ø160 [W] 4,9 6,9 8,9 X X
Power Ø100 [W] 3,9 5,9 7,9 X X
Flow rate Ø160 [m³/h] 30 45 60 X X
Flow rate Ø100 [m³/h] 15 22,5 30 X X
Noise at 3 m Ø160 [dB] 13 20 23 X X
Noise at 3 m Ø100 [dB] 19 24 29 X X
Max efficency 93% 93% 93% X X
