22 | VEHICLE HEATERS – TECHNICAL DOCUMENTATION
Program memory P1 display, factory setting.
1
Mo. - Fr. 21 °C
07 : 00 30 min.
Program memory P2 display with programmed
preselection.
2
Mi. 21 °C
06 : 30 60 min.
Press the button to confirm the selected pro-
gram memory.
ACTIVATING / DEACTIVATING THE PROGRAM MEMORY
Use the
or button to select the “On” or “Off”
setting.
2
Off
On
2
Off
On
Confirm the “On” or “Off” setting with the but-
ton, the program, e.g. P2 is activated or deactivated.
3 OPERATION AND SETTING/ADJUSTMENT
PROGRAM PRESET TIMES
Display ON, the Start display appears.
Use the
or button to select the symbol in
the Menu bar.
Display, if no preselection is activated.
1
2
3
Display, if a preselection is activated e.g. P2.
1
2
3
Confirm the PROGRAM menu item by pressing the
button.
PLEASE NOTE!
If the
symbol is marked with , a or several pro-
gram memories is/are already activated.
Activated program memories are marked in the dis-
play with a .
EASYSTART TIMER SETTINGS
SELECTING THE PROGRAM MEMORY
The P1 program memory is displayed, if applicable,
use the
or button to select the next program
memory P2, P3 or P1 again.
