USERS MANUAL
EBS MULTICOMP - BLUE LABEL EDITION
www.ebssweden.com
TECHNICAL SPECIFICATIONS EBS MULTICOMP Studio Edition
Nominal Input Level -10 or -4 dBv
Input Impedance 1.8 Mohms
Bandwidth +0/-3 dB 20 - 20k Hz
Gain Range 0 - 15 dB (makeup)
Compressor Ratio min/max 1:1 - 5:1
Sensitivity Range (Threshold) -25 - +6 dB
Attack Time (80%) <10 ms
Release Time (80%) typ. 100 ms
Dimensions W x H x D 2.6” x 4.5” x 1.9” (67 x 115 x 48 mm)
Weight 315g (0.7 lb.)
Type Analog Effect, Relay type Switching
Power Requirements 9, 12 or 18 V DC, 45 mA max.
Pedal shuts off below 6.0 V
Specifications are subject to change without notice.
A PRODUCT BY EBS SWEDEN AB
GRINDSTUVÄGEN 44-46, 167 33 BROMMA, SWEDEN
+46 8 735 00 10 | INFO@EBSSWEDEN.COM
