EBS WX2NB - 2 Functional and Technical Parameters

WX2NB Manual v.1.0 Page 6 / 40
2. FUNCTIONAL AND TECHNICAL PARAMETERS
Inputs:
(programmable)
4 signal inputs (NO, NC, EOL-NO, EOL-NC, DEOL-NO,
DEOL-NC),
1 DTMF
Outputs:
(programmable)
1
Operation modes:
 Wi-Fi transmission
 Serverless
Configuration:
Remote – via Wi-Fi network
Locally –from PC with the use of software and GD-PROG
cable with RS-232 link
Security:
Wi-Fi transmission – AES encoding
Loading of OUT1 output
50 mA
Working temperature
-10ºC ~ +55 ºC
Operating humidity
5% - 93%
In dependence from user's decision transmitter can be delivered in different
versions. Therefore also the parameters as type of the power supply voltage,
current consumption as well as the dimensions were introduced for following options
separately:
Option 1 – Transmitter WX2NB + power supply LX-ZAS in metal/plastic box
Option 2 – PCB of transmitter WX2NB
Option 1
Option 2
Voltage
typ. 230 V AC
(190 – 250 V AC)
50 – 60 Hz
typ. 12 V DC
(12 – 14 V DC)
Current consumption
(average/max)
90 mA / 350 mA
73 mA / 345 mA
Power consumption
(average/max)
3 W / 10 W
(recommended transforer 20W)
Dimensions
255 x 255 x 90 mm
(metal/plastic box)
102 x 73 x 35 mm
