Ebyte E01-ML01DP5 - Antenna Recommendation

Chengdu Ebyte Electronic Technology Co.,Ltd. E01-ML01DP5 User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co.,Ltd. 7
8. E01 Series
Model No.
IC
Frequency
Tx power
Test
distance
Package
Antenna
Hz
dBm
km
E01-ML01S
nRF24L01P
2.4G
0
0.1
SMD
PCB
E01-ML01D
nRF24L01P
2.4G
0
0.1
DIP
PCB
E01-ML01IPX
nRF24L01P
2.4G
0
0.2
SMD
IPEX
E01-ML01DP4
nRF24L01P
2.4G
20
1.8
DIP
PCB
E01-ML01DP5
nRF24L01P
2.4G
20
2.5
DIP
SMA-K
E01-ML01SP2
nRF24L01P
2.4G
20
1.8
SMD
PCB/IPEX
E01-ML01SP4
nRF24L01P
2.4G
20
2
SMD
IPEX
E01-2G4M27D
nRF24L01P
2.4G
27
5
DIP
SMA-K
9.Guidance for choosing antenna
9.1 Antenna recommendation
Antenna plays important role in the communication process. Good antenna can largely improve the communication
system. Therefore, we recommend some antennas with excellent performance and reasonable price.
Model
Type
Frequency
Hz
Interface
Gain
dBi
siza
Fender
Feature
TX2400-NP-5010
FPC
2.4G
IPEX
2
50*10mm
-
FPC
TX2400-XP-150
Sucker
2.4G
SMA-J
3.5
15cm
150cm
High gain
TX2400-JK-20
Whip
2.4G
SMA-J
3
200mm
-
Omnidirectional antenna
TX2400-JK-11
Whip
2.4G
SMA-J
2.5
110mm
-
Omnidirectional antenna
TX2400-JZ-3
Whip
2.4G
SMA-J
2
30mm
-
Omnidirectional antenna
