5.1.5 Address（unicast）,element
One address corresponds to one element, as can be seen from the model introduction above, we have three elements, we can call
it element address, it is the unique address assigned by the provision device to the node during the provision (networking) process In
the same mesh network, each node device may have multiple addresses. However, a model in each device can only have one address,
but different models can be bound to an address, in the subsequent mesh network communication process. The medium device is
relying on this address to find other devices.
5.2 BT11 function
There are E104-BT11-G and E104-BT11-N.
E104-BT11-G(short as BT11-G), it is provisioner
，
BT11-G is the initiator of the entire network. It is unique in one network with
features as follows
：

cannot communicate with nodes
；

Max configurable nodes is thirteen;

The node role can be configured as normal, relay, proxy, low power consumption, friend role
；
White list configuration is available
；
Only for setting one NETKEY and one APPKEY;
E104-BT11-N(short as BT11) it is node module
，
good for normal, relay, proxy, low power consumption, friend role with features
as follows
：

Support all role configuration of ble mesh
；

Support format transmission, transparent transmission
；

Support air configuration
；
5.2.1 Networking
Networking is to use BT11-G to add BT11-N to the BT11-G network. Therefore, at least two modules are required to implement
mesh networking, one BT11-G and one BT11-N.
