Chengdu Ebyte Electronic Technology Co., Ltd E104-BT11 User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
6 Quick Start
6.1 Factory reset
Send the following command 02 C0 15 (restore the factory) and then you will receive a return, 03 43 15 00 00,
E104-BT11-G and E104-BT11-N command format is consistent.
6.2 Access to network
E104-BT11-G test board and E104-BT11-N are plugged into the computer USB interface respectively (PC needs to install USB to
serial drive, see the data compression package for details), open the serial debugging assistant and select the baud rate 115200bps, 8
data bits, no school Check, 1 stop bit.
STEP 1. Set NETKEY first, then
APPKEY;
STEP 1. Send the device network connection instruction to configure the node network connection. After the configuration is
successful, the following data is returned, which indicates that the MAC address is: 09 BE A7 44 E2 0A 68, the network
address is: 0x0001, the number of elements is: 2
STEP 2. Repeat STEP2, continue to configure module
To Next Page
