Chengdu Ebyte Electronic Technology Co., Ltd E104-BT11 User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co.,Ltd
5.4.2.1 Fixed-point transmission example
Module 0x0003 sends "30313233343536373839" hex data to module 0x0001
0D C2 00 03 30 31 32 33 34 35 36 37 38 39
0F 42 00 01 00 03 30 31 32 33 34 35 36 37 38 39
5.4.2.2 Broadcast example
The device 0x0003 broadcasts the data "30313233343536373839". Other modules in the network receive broadcasts. Take
module 0x0001 and module 0x0005 as examples.
0D C2 ff ff 30 31 32 33 34 35 36 37 38 39
0F 42 00 03 FF FF 30 31 32 33 34 35 36 37 38 39
0F 42 00 03 FF FF 30 31 32 33 34 35 36 37 38 39
5.4.3 Configuration over air
Transparent
transmission
target address
（
2 byte
）
Transparent
transmission
enables
07 C3 00 001 00 002 0C 11 03
07 40 00 001 00 002 0C 11 03
1. Check digit parameters are consistent with 3.1.25 check digit setting configuration parameters;
2. The data bit parameters are consistent with the 3.1.21 setting uart data bit configuration parameters;
3. The stop bit parameters are consistent with 3.1.23 setting uart stop bit configuration parameters;
4. The baud rate parameter is consistent with the 3.1.11 baud rate setting configuration parameter
5. The restart function is to restart after configuration. 1 means restart, 0 means no restart.
6. Transparent transmission enable indicates that transparent transmission is enabled and prohibited. 1 is enabled, 0 is
disabled.
7. Any node can initiate air configuration.
8. Among them, the UART configuration restart takes effect and is saved after power-off;
9. Restart and transparent transmission enable will take effect immediately, save after power off.
Note:
After configured for transparent transmission, uart will no longer receive configuration parameters. If you need to set the
module through uart, you need to cancel the transparent transmission enable through the air configuration, or use the
restart pin to restart the parameters.
