Ebyte E104-BT11 User Manual

Chengdu Ebyte Electronic Technology Co., Ltd E104-BT11 User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co.,Ltd
22
5.4.1.27 Low-power node configuration
Operation
code
Parameter
Request
0x0C
enable
（1bytes）
Queue length in Friend role
(1bytes)
Time gap for pooling Frendi node
(4 bytes)
01
4
32
Response
0x0C
Same as request
For
example,
Request
08 C0 0C 01 05 00 00 0F A0
Response
08 40 0C 01 05 00 00 0F A0
Remark
1. This directive only applies to BT11
2. Queue length support range: 2~128, and the number of queues is even; the default is 2 queues
3. The unit of time gap is ms, and the supported range is: 1s ~ 95h59min900ms; default 4000ms
4. Take effect next time, save after power off
5.4.1.28 Low-power node acquisition
Operation
code
Parameter
Request
0x20
N/A
Response
0x20
See low-power node setting parameters
For example,
Request
02 C0 20
Response
08 40 20 01 05 00 00 0F A0
Remark
This directive only applies to BT11
5.4.2 Format transmission
 BT11 supports user data format transmission,
 The maximum length of serial port sub-packet is 241 bytes.
 Ble mesh does not support continuous data transmission, and a certain gap time is required between each two data. The
data format is as follows:
 BT11 supports fixed-point transmission and broadcast transmission. The broadcast transmission address within the group is
0xFFFF.
 BT11-G does not support data transmission function.
TX
Operation code（1 byte）
Target address（2 byte）
Data
0xC2
00 01
Valid data
RX
command（1 byte）
My address（2 byte）
Original address（2 byte）
Data
0x42
00 01
00 04
Valid data
