Ebyte E22-230T22S - 3 Size and Pin Definition

Chengdu Ebyte Electronic Technology Co., Ltd. E22-230T22S User manual
Copyright ©2012–2018，Chengdu Ebyte Electronic Technology Co.,Ltd.
8
TX length
240 Byte
Can be configured via command as
32/64/128/240 bytes per packet to transmit
Buffer
1000 Byte
Modulation
GFSK
LoRa
Communication interface
UART
Package
SMD
Connector
1.27mm
Size
16 * 26 mm
Antenna
IPEX/stamp hole
50 ohm impedance
3 Size and pin definition
No.
Name
Direction
Function
1
GND
Ground
