Chengdu Ebyte Electronic Technology Co., Ltd. E22-400T30D User Manual
Copyright ©2012–2018,Chengdu Ebyte Electronic Technology Co.,Ltd.
16
100: 9.6k
101: 19.2k
110: 38.4k
111: 62.5k
04H
Read/Wr
ite
REG1
76 Sub packet setting
00: 240 bytesdefault
01: 128 bytes
10: 64 bytes
11: 32 bytes
--------------------------------------
5 RSSI Ambient noise enable
1: Enable
0: Disabledefault
--------------------------------------
432 Reserve
--------------------------------------
10 Transmitting power
0030dbmdefault
0127dbm
1024dbm
1121dbm
When the data is smaller than the sub packet length,
the serial output of the receiving end is an
uninterrupted continuous output.
When the data is larger than the sub packet length,
the receiving end serial port will output the sub
packet.
--------------------------------------------
When enabled, the C0 C1 C2 C3 command can be
sent in the transmitting mode or WOR transmitting
mode to read the register.
Register 0x00: Current ambient noise rssi
Register 0X01: rssi when the data was received last
time.
Current channel noise is: dBm =-RSSI/2
Command format: C0 C1 C2 C3 + starting address +
read length
Returns: C1 + address address + read length + read valid
value
E.g: send C0 C1 C2 C3 00 01
Return C1 00 01 rssi
----------------------------------
Power and current are nonlinear, and power
efficiency is highest at maximum power.
The current does not decrease in proportion to the
decrease in power.
05H
Read/Wr
ite
REG2
Channel controlCH
0-83 represents a total of 84 channels
Frequency= 410.125 + CH *1M
06H
Read/Wr
ite
REG3
7 Enable RSSI
1Enable
0Disabledefault
--------------------------------------
6 Transmission mode
When enabled, the module receives wireless data
and it will follow an RSSI strength byte after output
via the serial port TXD
.---------------------------------------
The module recognizes the first three bytes of the
serial data as: address high + address low + channel
and takes it as the wireless transmitting target.
