14 Antenna recommendation
The antenna is an important role in the communication process. A good antenna can largely improve the
communication system. Therefore, we recommend some antennas for wireless modules with excellent performance and
reasonable price.
Model No.
Type
Frequency
Hz
Interface
Gain
dBi
Height
Cable
Function feature
TX433-NP-4310
Flexible
pcb
antenna
433M
SMA-J
2
43.8*9.5mm
-
Embedded FPC antenna
TX433-JW-5
Rubber
antenna
433M
SMA-J
2
50mm
-
Flexible
&omnidirectional
TX433-JWG-7
Rubber
antenna
433M
SMA-J
2.5
75mm
-
Flexible
&omnidirectional
TX433-JK-20
Rubber
antenna
433M
SMA-J
3
210mm
-
Flexible
&omnidirectional
TX433-JK-11
Rubber
antenna
433M
SMA-J
2.5
110mm
-
Flexible
&omnidirectional
TX433-XP-200
Sucker
antenna
433M
SMA-J
4
19cm
200cm
Sucker antenna, high
gain
TX433-XPL-100
Sucker
antenna
433M
SMA-J
3.5
18.5cm
100cm
Sucker antenna, high
gain
TX433-XPH-300
Sucker
antenna
433M
SMA-J
6
96.5cm
300cm
Car sucker antenna, ultra
high gain
TX433-JZG-6
Rubber
antenna
433M
SMA-J
2.5
52mm
-
Short straight
&omnidirectional
TX433-JZ-5
Rubber
antenna
433M
SMA-J
2
52mm
-
Short straight
&omnidirectional
TX490-JZ-5
Rubber
antenna
470/490M
SMA-J
2.0
50mm
-
Short straight
&omnidirectional
E22-400T22S
SX1268
430M 470M
22
7
SMD
16*26
UART
E22-400M30S
SX1268
433M 470M
30
12
SMD
24*38.5
SPI
E22-900M30S
SX1262
868M 915M
30
12
SMD
24*38.5
SPI
E22-900M22S
SX1262
868M 915M
22
6.5
SMD
14*20
SPI
E22-400M22S
SX1268
433M 470M
22
6.5
SMD
14*20
SPI
E22-230T30S
SX1262
230M
30
10
SMD
40.5*25
UART
E22-400T30S
SX1268
430M 470M
30
10
SMD
40.5*25
UART
E22-900T30S
SX1262
868M 915M
30
10
SMD
40.5*25
UART
