ene Chengdu Ebyte Electronic Technology Co, Ltd. E22-900M30S User manual
Main parameter Description Remark
Test condition : clear and open area, antenna gain: 5dBi, antenna
Distance for reference 12000m height 2.5m. air data rate: 0.3kbps
FIFO 256Byte Maximum length of single transmission
Crystal frequency 32MHz
Modulation LoRa(recommended)
Package SMD
Connector 2.54mm Stamp hole
Communication interface SPI 0-10Mbps
Size 38.5% 24*3.6 mm
Antenna IPEX/TPEX 50 ohm impedance
