Ebyte E22 T30D Series User Manual

Chengdu Ebyte Electronic Technology Co., Ltd. E22-xxxT30x series product user manual
Copyright©2012–2024, Chengdu Ebyte Electronic Technology Co., Ltd.
7
frequency
236.125MHz
493.125MHz
930.125MHz
Air speed
bps
2.4K～15.6K
2.4K～62.5K
2.4K～62.5K
Support ISM frequency band
blocking
power
dBm
10
10
10
Controlled by programming
Launch length
Btye
240
240
240
Less chance of burning when
used at close range
2.2 Electrical parameters
2.2.1 E22-230/400/900T30D electrical parameters
Electrical parameters
unit
model
Remark
E22-230T30D
E22-400T30D
E22-900T30D
Operating Voltage
V
2.7～5.5
2.7～5.5
2.7～5.5
≥ 5 V can guarantee the output
power , exceeding 5.5 V will
permanently burn the module .
Communication level
V
3.3V
3.3V
3.3V
There is risk of burning out by
using 5V TTL
Power
consumption
Transmitting
current
mA
530
515
525
Instantaneous power
consumption@30dBm
Receiving
current
mA
14
14
14
Sleep
current
uA
2
2
2
Software shutdown
temperature
Operating
temperature
℃
-40～+85
Industrial grade design
Storage
temperature
℃
-40
～
+85
Industrial grade design
2.2.2 E22-230/400/900T30S electrical parameters
Electrical parameters
un
it
model
Remark
E22-230T30S
E22-400T30S
E22-900T30S
Operating Voltage
V
2.7～5.5
2.7～5.5
2.7～5.5
≥ 5 V can guarantee the output
power , exceeding 5.5 V will
permanently burn the module .
Communication level
V
3.3V
3.3V
3.3V
There is risk of burning out by
using 5V TTL
Power
consumption
Transmitting
current
m
A
610
610
610
Instantaneous power
consumption@30dBm
