Receiving
current
m
A
14
14
14
Sleep current
uA
2
2
2
Software shutdown
temperature
Operating
temperature
℃
-40～+85
Industrial grade design
Storage
temperature
℃
-40～+85
Industrial grade design
2.3 Hardware parameters
2. 3.1 E22-230/400/900T30D hardware parameters
Hardware
parameters
model
Remark
E22-230T30D
E22-400T30D
E22-900T30D
chip
SX1262
SX1268
SX1262
-
Crystal
frequency
32MHz
Industrial grade high-precision crystal
oscillator
Modulation
LoRa
New generation LoRa modulation
technology
Communication
Interface
UART serial port
TTL level
Launch length
240Byte
Subpackage 32/64/128/240 bytes can be
set to be sent through commands
Packaging
method
Direct plug- in
-
cache capacity
1000Byte
-
Antenna
interface
SMA-K
Equivalent impedance is about 50 Ω
size
24*43mm
±0.1mm
Product Weight
11g
±0.2g
2. 3.2 E22-230/400/900T30S hardware parameters
Hardware
parameters
model
Remark
E22-230T30S
E22-400T30S
E22-900T30S
chip
SX1262
SX1268
SX1262
-
Crystal
frequency
32MHz
Industrial grade high-precision crystal
oscillator
Modulation
LoRa
New generation LoRa modulation
