Chengdu Ebyte Electronic Technology Co,;Ltd E32-433T20S1 user manual
Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd.
15
1
1
8N1 (equal to 00)
5
4
3
TTL UART baud rate（bps）
 UART baud rate can be different between
communication parties
 The UART baud rate has nothing to do
with wireless transmission parameters &
won’t affect the wireless transmit / receive
features.
0
0
0
1200
0
0
1
2400
0
1
0
4800
0
1
1
9600 (default)
1
0
0
19200
1
0
1
38400
1
1
0
57600
1
1
1
115200
2
1
0
Air data rate（bps）

The lower the air data rate, the longer the
transmitting distance, better
anti-interference performance and longer
transmitting time

The air data rate must keep the same for
both communication parties.
0
0
0
0.3k
0
0
1
1.2k
0
1
0
2.4k (default)
0
1
1
4.8k
1
0
0
9.6k
1
0
1
19.2k
1
1
0
19.2k (same to 101)
1
1
1
19.2k (same to 101)
General Specifications
Except for E32 (400T20S)
4
CHAN
7
6
5
reserved
Write 0
Communication channel
00H-1FH, correspond to 410~441MHz
4-0, channel (410M + CHAN*1M), default 17H（433MHz）
5
OPTIO
N
7
Fixed transmission enabling bit（similar to MODBUS）
 In fixed transmission mode, the first three
bytes of each user's data frame can be used
as high/low address and channel. The
module changes its address and channel
when transmit. And it will revert to original
setting after complete the process.
0
Transparent transmission mode
1
Fixed transmission mode
6
IO drive mode (default 1)

This bit is used to the module internal
pull-up resistor. It also increases the
level’s adaptability in case of open drain.
But in some cases, it may need external
pull-up resistor.
1
TXD and AUX push-pull outputs, RXD pull-up inputs
0
TXD、AUX open-collector outputs, RXD open-collector
inputs
5
4
3
wireless wake-up time
 The transmit & receive module work in
mode 0, whose delay time is invalid & can
be arbitrary value.
 The transmitter works in mode 1 can
transmit the preamble code of the
corresponding time continuously.
 When the receiver works in mode 2, the
0
0
0
250ms (default)
0
0
1
500ms
0
1
0
750ms
0
1
1
1000ms
1
0
0
1250ms
1
0
1
1500ms
