Ebyte E32-868T20D User Manual

Chengdu Ebyte Electronic Technology Co,;Ltd E32-868T20D user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co.,Ltd. 15
0
1
1
1000ms
preamble code of the corresponding time
continuously.
 When the receiver works in mode 2, the time
means the monitor interval time (wireless
wake-up). Only the data from transmitter that
works in mode 1 can be received.
1
0
0
1250ms
1
0
1
1500ms
1
1
0
1750ms
1
1
1
2000ms
2
FEC switch
 After turn off FEC, the actual data transmission
rate increases while anti-interference ability
decreases. Also the transmission distance is
relatively short.
 Both communication parties must keep on the
same pages about turn-on or turn-off FEC.
0
Turn off FEC
1
Turn on FEC (default)
1
0
Transmission power (approximation)
The external power must make sure the ability of
current output more than 1A and ensure the power
supply ripple within 100mV.
Low power transmission is not recommended due to
its low power supply efficiency.
0
0
30dBm (default)
0
1
27dBm
1
0
24dBm
1
1
21dBm
For example: The meaning of No.3 "SPED" byte:
The binary bit of the byte
7
6
5
4
3
2
1
0
Configures by user
0
0
0
1
1
0
1
0
Meaning
UART parity bit 8N1
UART baud rate is 9600
Air data rate is 2.4k
Corresponding hexadecimal
1
A
8. Hardware design
 It is recommended to use a DC stabilized power supply. The power supply ripple factor is as small as possible, and
the module needs to be reliably grounded.；
 Please pay attention to the correct connection of the positive and negative poles of the power supply. Reverse
connection may cause permanent damage to the module；
 Please check the power supply to ensure it is within the recommended voltage otherwise when it exceeds the
maximum value the module will be permanently damaged；
 Please check the stability of the power supply, the voltage can not be fluctuated frequently；
 When designing the power supply circuit for the module, it is often recommended to reserve more than 30% of the
margin, so the whole machine is beneficial for long-term stable operation.；
 The module should be as far away as possible from the power supply, transformers, high-frequency wiring and other
parts with large electromagnetic interference.；
 High-frequency digital routing, high-frequency analog routing, and power routing must be avoided under the
module. If it is necessary to pass through the module, assume that the module is soldered to the Top Layer, and the
copper is spread on the Top Layer of the module contact part(well grounded), it must be close to the digital part of
the module and routed in the Bottom Layer；
