Chengdu Ebyte Electronic Technology Co,;Ltd E32-868T20D user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co.,Ltd. 5
Modulation
LoRa™
Communication interface
TTL
@3.3V
Package
DIP
Connector
2.54mm
Size
21 * 36mm
Antenna
SMA-K
50 ohm impedance
3 Size and pin definition
No.
Name
Direction
Function
1
M0
Input
（weak pull-up）
Work with M1 to decide 4 working modes of module (not suspended, if
not used, could be grounded).
2
M1
Input
Work with M0 to decide 4 working modes of module (not suspended, if
