Copyright ©2012–2022，Chengdu Ebyte Electronic Technology Co.,Ltd 4
3. Installation Specifications
3.1. Structure
Pin
NO.
Name
Function
Description
1
DB-9 female socket
RS-232 interface
Standard RS-232 interface
2
3.81 terminal block
RS-485, power interface
Standard RS-485 interface and pressure line
power interface
3
PWR-LED
Power LED
Red, lit when the power is on
4
TXD-LED
Transmit LED
Yellow, blinks when sending data
