EC-80320 User’s Manual
- 24 -
Chapter 5 Features
5.1 General Specification
Item Description
Print method Direct thermal printing
Print direction Line printing
Paper width 72 mm
Print speed 220mm/s（52line/s）
Print head Lifespan: 100 Km
Resolution 8 dot/mm, 576dot/line, 203DPI
Character set
ASCII: 13 international character sets
Chinese: GB 18030
Code page 9 kinds
Bard code UPC-A、UPC-E、EAN-13、EAN-8、Code39、Code128、ITF-25、Codabar
Life space 1/6 inch, or programmable in 1/203 inch increments
Paper feed speed 220 mm/s at most
Emulation ESC/POS
Interface
Parallel interface（Centronics）+ Drawer interface（CPC6）
USB interface（2.0 Full-Speed）+ Drawer interface（CPC6）
USB interface（2.0 Full-Speed）+ Serial interface（RS-232C）+ Drawer interface
（CPC6）
USB interface（2.0 Full-Speed）+ Ethernet interface（10/100Base-T）+ Drawer
kick-out interface（CPC6）
*Only equip with one assembled interface when leaving factory.
Buffer
4MB
Noise
＜38 dB (A)
Control panel
The control panel consists of one key and three LED indicators.
Paper type
Thermal roll paper
Paper specification
Thermal roll paper model: TF50KS－E（Japan paper co.ltd）
AF50KS-E（JUJO THERMAL）
Width: 79.5 ± 0.5 mm
Weight: 53 ～ 80 g/m
2
Maximum diameter: 80 mm
*Suggestion: Inner diameter of paper shaft:12mm, Outer diameter of paper
shaft:18mm
Physical dimensions
145 mm（Width）× 200 mm（Depth）× 145 mm（Height）
Weight
About 2Kg
Operating environment: temperature: 5 ～ 50℃
Humidity: 10%RH ～ 80%RH（No condensation）
Environmental
conditions
Storage environment: temperature: -20 ～ 60℃
Humidity: 10%RH ～ 90%RH（No condensation）
Input voltage: 176 ～ 242 V
Frequency: 50Hz/60Hz
Power requirements
Output voltage: DC24 V
