PLEASE NOTE: THIS MODEL IS FOR INDOOR PERMANENT INSTALLATIONS ONLY.
F = Clearance to outside corner *
G = Clearance to inside corner *
H = Clearance to each side of
center line extended above
meter /regulator assembly
* 3 ft (91 cm) within a height 15
ft above the meter/regulator
assembly
I = Clearance to service
regulator vent outlet
* 3 ft (91 cm)
J = Clearance to non-
mechanical air supply
inlet to building or the
combustion air inlet to any
other appliance
4 ft (1.2 m) below or to side
of opening; 1 ft (300 mm)
above opening
6 in (15 cm) for appliances ≤
10,000 Btuh (3 kW), 12 in (30
cm) for appliances > 10,000
Btuh (3kW) and ≤ 100,000
Btuh (30 kW), 36 in (91 cm)
for appliances >
100,000 Btuh (30 kW)
K = Clearance to a mechanical
air supply inlet
3 ft (91 cm) above if within
10 ft (3 m) horizontally
6 feet (1.83 m)
L = Clearance above paved
sidewalk or paved driveway
located on public property
* 7 ft (2.13 m)
M = Clearance under veranda,
porch, deck or balcony
* 12 in (30)
* For clearances not specied in ANSI Z223.1 / NFPA 54 or CSA-B149.1, one of the following shall be indicated:
A) A minimum clearance value determined by testing in accordance with Clause 5.20, or;
B) A reference to the following footnote:
“Clearance in accordance with local installation codes and the requirements of the gas supplier.”
• A vent shall not terminate directly above a sidewalk or paved driveway that is located between
two single family dwellings and serves both dwellings.
• Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath
the oor.
Notes:
1. In accordance with the current CSA B149.1 Natural Gas and Propane Installation Code
2. In accordance with the current ANSI Z223.1 / NFPA 54 National Fuel Gas Cod
