3.2.2.2 ALARM LOG
Pressing the Alarm log button will give you the screen which will inform you of the triggered alarms. It will state the
occurrence of the alarm, the message associated with the occurrence.
3.2.2.3 CONFIG (CONFIGURATION MENU)
Three options are available in the Configure Menu, Display, Ethernet Settings, and Re-Scan Sensors.
Configure Display
o Screen Save ON/OF
o Timeout (20 min)
Configurable using number entry screen
o Beep ON/OFF
o Brightness level
Configurable using the left and right arrow keys
o Menu Timeout (2 min)
Configurable using number entry screen
o Time/Date
Time and date is set up as:
Hours: Minutes: Seconds
Month: Day: Year
Ethernet Settings
o IP Address configuration
o Subnet Mask configuration
o Default Gateway Configuration
Re-Scan Sensors
o The Controller will re-scan and refresh sensor inputs
3.2.2.4 INFO (INFORMATION MENU)
The Information Menu provides two choices:
System Information: details the Firmware Revision, HMI, PLC, Serial Number, and System Runtime
System Information: Ethernet, IP Address, Subnet Mask, Default Gateway
3.2.3 START UP GUIDE
Install and wire the LQ800 Transmitter as described in Sections 2.3 and 2.4 above. Connect the sensor to the transmitter
as described in Section 2.4. Supply power to the Model LQ800 transmitter.
Verify the proper measurement type is displayed, pH, ORP, pION, turbidity, DO, Level, or other parameter. The sensor
automatically uploads the measured parameter, the calibration data, and the range of measurement to the transmitter.
The default configuration of the 4-20 mA output is the range of the sensor, 0-14 pH for pH sensors, -1500 - +1500 for
ORP or 0-XXXX ppm for a pION Sensor. To change the 4-20 mA range, follow the instructions in Section 3.2.3.1 below.
