7.1.3 MODEL CODES
Model T80-
1
st
Channel
1
(S80) S80 Digital Sensor, pH, ORP, pION, DO, DO90 ppb DO, Conductivity, Resistivity
2
Internal Preamp, Digital to S10/S17 pH, ORP, pION (+mV, -mV, 100K TC, SG)
3
Internal Preamp, Digital to SGTC Conductivity/Resistivity (CSX2 or 2 electrode contacting)
4
Internal Preamp, Digital to SGTC Dissolved Oxygen (Steam Sterilizable Products)
2
nd
Channel
0
No Second Channel
1
(S80) S80 Digital Sensor, pH, ORP, pION, DO Conductivity, Resistivity
Power Supply
-0
Loop Powered Transmitter
-1
24 VDC Powered Transmitter
-2
100-240 VAC Powered Transmitter
Relay Option
0
No relays
1
(3) form 1C 250 V 3A relays
Outputs
0
4-20 mA output and MODBUS
1
HART®
2
2 x 4-20 mA & MODBUS
Mounting
Hardware
00
No Mounting
01
Universal
02
Panel Mount
03
Handrail Mount
04
Sunshield Pole
05
Sunshield Rail
Model T80-
1
1
-2
1
2
01
Example above shows # T80-11-212-01, a two channel T80 transmitter for use with two S80 sensors, 110/220
VAC powered with two 4-20 mA outputs and MODBUS RTU and a universal mounting bracket.
