ECD T80 Instructional Manual

HYDRA-DS NO
3
-N Page 46
Relay ON Setpoint (hi word)
Read/Write Relay ON Setpoint (byte 3 and byte 2)
2
32 bit
Floating
Point
RW
Y
23
17
Relay ON Setpoint (lo word)
Read/Write Relay ON Setpoint (byte 1 and byte 0)
24
18
Relay OFF Setpoint (hi
word)
Read/Write Relay OFF Setpoint (byte 3 and byte 2)
2
32 bit
Floating
Point
RW
Y
25
19
Relay OFF Setpoint (lo
word)
Read/Write Relay OFF Setpoint (byte 1 and byte 0)
26
1A
Relay ON Delay (hi word)
Read/Write Relay turn on Delay time (byte 3 and
byte 2)
2
32 bit
Floating
Point
RW
Y
27
1B
Relay ON Delay (lo word)
Read/Write Relay turn on Delay time (byte 1 and
byte 0)
28
1C
Relay OFF Delay (hi word)
Read/Write Relay turn off Delay time (byte 3 and
byte 2)
2
32 bit
Floating
Point
RW
Y
29
1D
Relay OFF Delay (lo word)
Read/Write Relay turn off Delay time (byte 1 and
byte 0)
30
1E
Relay Energized State
Read/Write Relay 0 - Energized, 1 - De-Energized
1
16 bit
Integer
RW
Y
31
1F
Relay Expiration
Read/Write Expiration Time, used with alarm type (0
- None, 2 - 5min., 3 - 10min., 4 - 15min., 6 - 30min.)
1
16 bit
Integer
RW
Y
32
20
Relay Period
Read/Write Timed Relay Period (0 - 15min., 1 -
30min., 2 - 1hr., 3 - 2hr., 4 - 4hr., 5 - 8hr., 6 - 24hr.)
1
16 bit
Integer
RW
Y
33
21
Relay Duration
Read/Write Timed Relay Duration (0 - 15sec., 1 -
30sec., 2 - 1min., 3 - 2min., 4 - 5min., 5 - 15min., 6 -
10min.)
1
16 bit
Integer
RW
Y
34
22
Relay Hold Time
Read/Write Timed Relay Hold Time (0 - Off, 1 - held
for the duration time, 2 - duration + 15sec., 3 - duration
+ 30sec., 4 - duration + 1min., 5 - duration + 2min., 6 -
duration + 5 min., 7 - duration + 15min., 8 - duration +
30min.)
1
16 bit
Integer
RW
Y
35
23
4-20 mA Channel Number to
read/write
4-20 mA channel number to access data (0 - 1st 4-
20mA, 1 - 2nd 4-20)
1
16 bit
Integer
RW
Y
36
24
4-20 Analog Type
Read/Write 4-20 Type (0 - Range, 1 - Temperature, 2
- Sentinel)
1
16 bit
Integer
RW
Y
37
25
4-20 Analog Range, 4mA
range (hi word)
Read/Write 4mA range (bytes 3 and 2) applies to
both range and temperature types
2
32 bit
Floating
Point
RW
Y
38
26
4-20 Analog Range, 4mA
range (lo word)
Read/Write 4mA range (bytes 1 and 0) applies to
both range and temperature types
39
27
4-20 Analog Range, 20mA
range (hi word)
Read/Write 4mA range (bytes 3 and 2) applies to
both range and temperature types
2
32 bit
Floating
Point
RW
Y
40
28
4-20 Analog Range, 20mA
range (lo word)
Read/Write 4mA range (bytes 1 and 0) applies to
both range and temperature types
41
29
Long Tag Line number to
read/write
Tag Line number to access data (0 - Line 1, 1 - Line 2)
1
16 bit
Integer
RW
Y
42
2A
Long Tag Line 1 (16
characters max)
ASCII character bytes 0 and 1, ex. "AB" A - 65 (41
hexadecimal), B - 66 (42 hex), send 6566 (4142 hex).
The characters permitted are space ' ' (32 base 10, 20
hex) through '}' 125 base 10, 7D hex).
1
16 bit
Integer
RW
Y
43
2B
Long Tag Line
ASCII bytes 2 and 3
1
16 bit
Integer
RW
Y
44
2C
Long Tag Line
ASCII bytes4 and 5
1
16 bit
Integer
RW
Y
45
2D
Long Tag Line
ASCII bytes 6 and 7
1
16 bit
Integer
RW
Y
46
2E
Long Tag Line
ASCII bytes 8 and 9
1
16 bit
Integer
RW
Y
47
2F
Long Tag Line
ASCII bytes 10 and 11
1
16 bit
Integer
RW
Y
48
30
Long Tag Line
ASCII bytes 12 and 13
1
16 bit
Integer
RW
Y
49
31
Long Tag Line
ASCII bytes 14 and 15
1
16 bit
Integer
RW
Y
50
32
Initiate T80 Parameter
Storage
Signals the user has completed entering the data and
wants it stored. Write any value.
1
16 bit
Integer
RW
51
33
Sensor Channel to
read/write
Sensor channel number to access data (0 - Sensor 1,
1 - Sensor 2)
1
16 bit
Integer
RW
52
34
S80 Mode
Unit operating mode (0-
1
16 bit
Integer
R
53
35
