MAINTENANCE AND CLEANING
FILTRATION SYSTEM
The  lter protects the pump against penetration of larger pieces of food and other objects. Remains of food
may clog the  lter. Therefore it is necessary to remove and clean the  lter from time to time.
Filtration system consists of acoarse  lter, a at (main  lter) and a ne micro lter.
1 Flat  lter
The food remains and dirt are guided by aspecial jet on the lower
arm into this  lter.
2 Coarse  lter
This  lter captures the larger particles such as pieces of bone or
glass, which could clog the drain. If you need to remove trapped
particles from the  lter, gently squeeze the tabs at the top and pull
out the  lter.
3 Micro  lter
This  lter captures in the dirt trap small food particles and prevents
their returning on the dishes.
- Check after each use of the dishwasher that the  lter is not
clogged.
- After unscrewing the coarse  lter, you can remove the entire
 lter system. Remove all food remains and then rinse the  lter
under running water.
1
Step 1: Turn the  lter counterclockwise
andthenslide it out.
2
Step 2: Push the  at  lter upward.
Note:
• When removing the  lter proceed from step 1 to step 2, when inserting the  lter back proceed from step
2 to step 1 and install the  lter system 3.
Filter assembly
Regular  lter cleaning ensures optimum performance and washing results. The  lter e ectively captures
particles from the wash water and allows the recycling of water during the cycle. It is therefore advisable after
each wash cycle to remove from the  lter larger trapped particles by rinsing the  lter under running water.
Remove the  lter by pulling the tab of the  lter in the vertical direction. The whole  lter should be cleaned
once aweek.
Use acleaning brush to clean the coarse and  ne  lter. Then reassemble the  lter as shown above and insert
the entire  ltration system into the dishwasher back into position and push it downward.
