Front panel [B] andRemote control [C]
1. On/O switch
Press the button to turn the air conditioner on or o.
2. Automatic directing of airow
Press this button to start automatic turning of the slats to direct airow.
3. Fan speed button
You can select high, medium or low speed of the airow using this button.
4. Up/down buttons to set temperature or time.
Set temperature using these buttons in the cooling mode. Set time of turning on/o in the timer mode. By
simultaneously pressing both buttons (on the panel) you can switch between displaying the temperature
in Celsius or Fahrenheit.
5. Mode selection button
By pressing aspecic button on the remote control you can choose between modes of cooling, airow,
dehumidication and auto mode.
6. Timer button
Press button in standby mode to set time when to turn on the appliance. Press button when the appliance
is on to set time to turn it o.
7. Display showing temperature/time (appliance panel)
This window shows the set temperature and time.
8. Remote control sensor (appliance panel)
The sensor receives signals transmitted by remote control.
9. Button for switching between Celsius and Fahrenheit (remote control)
Press the button to switch between temperature scales.
PLACEMENT AND INSTALLATION
Installing the device
Place the appliance on alevel oor near awindow.
To ensure good air circulation and best performance there should be
at least 50 cm of free space around the appliance.
Installation
Exhaust hose assembly
Exhaust tube
Round connector Flat neck
Window seal assembly
1. Measure the window size
2. Adjust the length of the sealing strip so as to t the size of the window. After determining the length of the
sealing strip, x the set size using screw A.
3. Install the strip with xed length in the window.
4. Screw (counterclockwise) the exhaust hose assembly with the round connector to the hot air exhaust on
the rear side of the air conditioner B.
