11
INSTRUCTION MANUAL
FOLDING INSTRUCTIONS
Press the button under #A4 on the handlebar
to lift up and push back until an audible “click”
indicates that it is locked into place horizontally
with the uprights.
2
STEP
Rotate the #B1 console backwards so that
it is horizontal with the #A4 handlebars.
1
STEP
Recommended Storage: Place treadmill at standing
position against a wall for storage, or place it under
the bed to save space.
The height of the treadmill is 10.25 in (26 cm) when
laying horizontally. If the space is less than 10.25 in
(26 cm) High under your bed, try utilizing the
vertical space in your home.
5
STEP
For transport, lift up on the treadmill
from the backside to ensure heaviest
end is closest to the ground.
4
STEP
WHEN STORING THE TREADMILL IN AN
UPRIGHT POSITION, PLEASE INSTALL
SAFETY STRAPS TO THE WALL TO SECURE
AND PREVENT TREADMILL FROM
TIPPING OVER.
Use the provided anchors and screws to
install the safety straps. For concrete walls,
drill two 0.315 in (8 mm) pilot holes with
1.6 in (40 mm) depth, 32 in (81 cm) apart,
and 47.2 in (120 cm) above floor.
NOTE: For wood walls, locate two wall studs
32 in (81 cm) apart and drill appropriate
pilot holes. Drive screws into pilot holes
without anchors.
3
STEP
Step down on the #B147 rectangular shaped lever
to begin the auto folding process. Once complete,
the uprights and console will lay flat with
the running deck.
