Step 2: Connect the two communication wires between console frame and upright,
then put the console frame onto the upright by 8 M8 x 25 Allen flat head full thread bolt,
but don’t tighten them.
Step3: the LED display is pre-assembled with dashboard. Connect the communication
wire, insert the handgrip dashboard into the console frame with 2ea M8 x 45 Allen
LED
communication
Main
communication
wire
LED
communication
Main
communication
wire
To Next Page
