10
remove nylon lIne head
1. Align locking hole in upper plate with notch in edge of gear housing
and insert head locking tool (C).
2. Remove line head by turning it clockwise until head is completely
off of shaft.
3. Remove locking tool.
C
NOTE
Refer to the Grass Trimmer / Brush Cutter Safety Manual for proper and safe trimming techniques.
operaTIon
WARNING
Moving parts can amputate ngers or cause severe injuries. Keep hands, clothing and loose objects away from all
openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop
before removing obstructions, clearing debris, or servicing unit.
To advanCe TrImmer lIne
See Maintenance Section for nylon line replacement.
NOTE
To advance trimmer line, tap trimmer head against the ground while the head is turning at normal operating speed.
