BRD-2620 SPECIFICATIONS
X7502343001 41
© 09/2019 ECHO Inc.
SPECIFICATIONS
MODEL BRD-2620
Length 1797 mm (70.7 in.)
Width 301 mm (11.9 in.)
Height 328 mm (12.9in.)
Weight (dry) with dry
head
8.06 kg (17.7 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline
engine
Bore 34.0 mm (1.34 in.)
Stroke 28 mm (1.1 in.)
Displacement 25.4 cc (1.55 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler
with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge
ignition type
Spark Plug NGK CMR7H - Gap 0.6 - 0.7 mm (0.024 -
0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50 : 1
Gasoline Use 89 Octane unleaded. Do not use fuel
containing methyl alcohol, more than 10%
ethyl alcohol or 15% MTBE. Do not use
alternative fuels such as E-15 or E-85.
Oil ISO-L-EGD (ISO/CD 13738) and J.A.S.O.
M345- FD, two-stroke, air-cooled engine oil.
Fuel Tank Capacity 0.61 lit. (20.6 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft 6.35 mm (1/4 in.) flexible shaft
Gear Case Ratio 2.07:1
Rotating Direction Counter Clockwise; viewed from right side
Standard Cutter Head Claw-style cutter (six carbride tips)
Optional Cutter Head 2-tooth edger blade
