CS-330T
1-2 Technical data
Model CS-330T CS-360T
Engine
Idling speed rpm 2400 - 2800 2400 - 2800
Wide open throttle speed* rpm 13000 - 14000 13000 - 14000
Clutch engagement speed rpm 4700 - 5000 4700 - 5000
Compression pressure MPa (kgf/cm
2
) (psi) 0.98 (10.0) (142) 0.97 (9.8) (140)
Ignition system
Spark plug gap mm(in) 0.6 - 0.7 (0.024 - 0.028)
Minimum secondary voltage at 1000 rpm kV 15
Secondary coil resistance kΩ 1.4 - 2.0
Pole shoe air gaps mm (in) 0.3 - 0.4 (0.012 - 0.016)
Ignition timing at 1000 rpm
°BTDC 25
at 3000 rpm °BTDC 3
at 8000 rpm °BTDC 32
at 14000 rpm °BTDC 15
Carburetor
Idle adjust screw initial setting turns in** 3
Test Pressure, minimum MPa (kgf/cm
2
) (psi) 0.05 (0.5) (7.0)
Metering lever height mm(in) 1.65 (0.06) lower than diaphragm seat
Chain oil discharge volume at 7000 rpm Adjustable : 1.5 - 13 (0.05 - 0.40)
mL/min(U.S.fl.oz./min) (Factory set 7 mL/min)
BTDC: Before top dead center.
*CS-330T: With 14 in. guide bar and saw chain.
CS-360T: With 16 in. guide bar and saw chain.
**Set idle adjust screw to contact throttle plate before initial setting.
