Echo CS-330T Service Data

4
SERVICE INFORMATION
CS-360T
CS-330T
1-3 Torque limits
Descriptions
Size
kgf•cm
N•m
in•lbf
Starter
system
Starter pawl
M 5*
40 - 60
4 - 6
35 - 50
Starte
r case M 4 15 - 25 1.5 - 2.5 13 - 22
Ignition
system
Magneto rotor (Flywheel)
M 8
200 - 240
20 - 24
175 - 210
Ignition coil
M 5*
30 - 45
3.0 - 4.5
26 - 40
Spar
k plug M 14 150 - 170 15 - 17 130 - 150
Fuel
system
Carburetor
M 5
30 - 45
3.0 - 4.5
26 - 40
Intake bellows
M 5
30 - 45
3.0 - 4.5
26 - 40
Clutch Clutch hub LM 10 230 - 260 23 - 26 200 - 230
Engine
Crankcase
M 5
70 - 90
7 - 9
60 - 80
Engine mount
M 5
70 - 110
7 - 11
60 - 95
Dus
t cover M 4**
10 - 20 1 - 2 9 - 18
Muffler
M 5
90 - 110
9 - 11
80 - 95
Muffler cover
M 4**
10 - 20
1 - 2
9 - 18
Others
Auto
-oiler M 4 15 - 25 1.5 - 2.5 13 - 22
Front handle
M 5
45 - 60
4.5 - 6.0
40 - 50
Top handle
M 4**
10 - 20
1 - 2
9 - 18
T
op handle assembly M 4**
20 - 30 2 - 3 18 - 26
Brake lever (Hand guard)
M 5
25 - 45
2.5 - 4.5
22 - 40
Chain catcher
M 4**
20 - 40
2 - 4
18 - 35
Guid
e bar stud M 6* 90 - 110 9 - 11 80 - 95
Guide bar
M 6
45 - 75
4.5 - 7.5
40 - 65
Regular bolt, nut,
and screw
M 3
6 - 10
0.6 - 1.0
5 - 9
M 4 15 - 25 1.5 - 2.5 13 - 22
M 5
25 - 45
2.5 - 4.5
22 - 40
M 6
45 - 75
4.5 - 7.5
40 - 65
LM: Left-hand thread *Apply thread locking sealant (See below) ** Tapping screw
1-4 Special repairing materials
Material Location Remarks
Adhesive Ball bearing outer / crankcase
Loctite #675 or equivalent
Guide bar stud
Muffler stud
Liquid gasket Crankcase seams Loctite #515 or equivalent
Thread locking sealant Starter pawl screws Loctite #242, ThreeBond #1324 or equivalent
Ignition coil Loctite #222, ThreeBond #1342 or equivalent
Grease Auto-oiler worm
Lithium based grease
Clutch needle bearing
Handle cushions
Rewind spring
Starter center shaft
Chain brake (metal contact part) Molybdenum grease (approx. 1 gram)
