9
STARTER SYSTEM
CS-350WES
4K287
C
B
A
C
C
2-2 Replacing starter rope
1. Pull out knot (A) and untie knot (A).
2. Pull out knot (C) from dent of rope reel (B).
3. When installing a new starter rope, singe both
ends of the rope to prevent fraying.
4. Make a knot (C) at end of starter rope and pass
the rope through hole of rope reel and press the
knot (C) into dent as shown.
5. Pass the other end of starter rope through rope
guide on starter case, then pass the starter rope
through starter grip and make a knot as shown.
To Next Page
