CS-501P
WHEN THE ENGINE IS COLD
CAUTION
Make sure the bar and chain are free from
any obstruction when starting the chain saw.
• Movechainbrakeleverfullyforwardtolock
chain brake before starting.
• Fillthefueltankwithfuelmixture.
It is not permitted to fill fuel above the shoulder
level of fuel tank.
• Fillthechainoiltankwithlubricant.
Do not over fill.
• Moveignitionswitchto“I ” position.
• Pullchokecontrolknoballthewayout.
(Choke position
)
• Pressthedecompressiondevice.
• Securelyholdthechainsawasshownand
pull starter handle several times until first firing
sound.
• Pushchokecontrolknoballthewayin.
• Pressthedecompressiondeviceandpullstarter
handle again to start the engine.
• Whenenginestarts,immediatelysqueezeand
release throttle trigger for disengaging throttle
latch and returning engine to idle, and pull front
hand guard towards the operator immediately.
(Chain brake unlocked position)
WHEN THE ENGINE IS WARM
CAUTION
Make sure the bar and chain are free from
any obstruction when starting the chain saw.
• Movechainbrakeleverfullyforwardtolock
chain brake before starting.
• Conrmthereisfuelandchainoilinthetanks.
• Moveignitionswitchto“I ” position.
• Pressthedecompressiondevice.
• Securelyholdthechainsawasshownandpull
starter handle.
• Chokemaybeusedifnecessary,butafterrst
firing sound, pull throttle trigger to release choke.
• Afterstartingtheengine,pullfronthandguard
towards the operator immediately.
(Chain brake unlocked position)
Ignition switch
Chain brake
Throttle trigger
Choke
Throttle trigger
lockout
Ignition switch
Unlock chain brake
Decompression device
Starter handle
Chain brake
Decompression
device
Starter handle
Unlock chain brake
