Echo CS-501P Instruction Manual

6
CS-501P
NOMENCLATURE OF PARTS
* If a decal cannot be read, a new one can be
ordered from your ECHO dealer.
21
16
17
19
18
5
4
8
7
10
11
12
3
1
X524-003551
X505-006660
9
23
6
24
22
20
15
Part Number X505-006660
13
14
2
Part Number X524-003551
REPLACEMENT BAR AND CHAIN
GUIDE BAR* CHAIN*
PART NO. PART NO.
16” 16F0LD3366 20LPX66CQ / 20BPX66CQ
18” 18F0LD3372 20LPX72CQ / 20BPX72CQ
20” 20F0LD3378 20LPX78CQ / 20BPX78CQ
*Or equivalent
Note:
There may be other replacement
components for achieving kickback
protection. For details, please refer
to the chain and bar combination
sheet shown in the instruction manual.

Echo CS-501P Specifications

General

Engine Displacement	50.2 cc
Chain Pitch	0.325 in
Chain Gauge	0.050 in
Bar Length	18 in
Fuel Capacity	0.5 liters
Oil Capacity	0.25 liters
Starting System	Recoil
Fuel Tank Capacity	0.5 liters
Oil Tank Capacity	0.25 liters
Weight (Powerhead Only)	10.6 lbs
