32
CS-501P
* Technical data subject to change without notice.
TECHNICAL DATA
MODEL
CS-501P
Dimension L × W × H mm 395 × 235 × 290 (15.6 in. × 9.3 in. × 11.4 in.)
Mass Power head, dry kg 4.7 (10.4 lb.) Without chain and guide bar
Engine Type Air-cooled two-stroke single cylinder
Displacement mL (cm³) 50.2 (3.06 cu. in.)
Carburetor Diaphragm type
Magneto Flywheel magneto: CDI system
Spark plug NGK BPM8Y
Starter Recoil starter
Power transmission Automatic centrifugal clutch
Fuel Mixture ratio
50:1ratiowithECHOPowerBlendX™,ISO-L-
EGD (ISO/CD 13738) and JASO M345-FD two-
stroke, air-cooled engine oil.
Gasoline Use 89 octane unleaded.
Do not use fuel containing methyl alcohol, more than
10 % ethyl alcohol or 15 % MTBE.
Do not use alternative fuels such as E-15 or E-85.
Tank capacity L 0.490 (16.6 US. fl. oz.)
Oil Bar and chain ECHO bar and chain oil
Tank capacity L 0.280 (9.47 US. fl. oz.)
Guide bar and
saw chain
See page 23 for Chain and Guide Bar Combination
Lubrication Adjustable automatic oil pump
Engine speed Idle
r/min
2300 - 3100
Clutch engagement 3600 - 4200
Wide open throttle 13000 - 13700
Standard
features
Front hand guard, Rear hand guard,
Anti-vibration device, Spiked bumper,
Throttle control lockout, Chain brake, Chain catcher,
Spark arrestor muffler

Echo CS-501P Specifications

General

Engine Displacement	50.2 cc
Chain Pitch	0.325 in
Chain Gauge	0.050 in
Bar Length	18 in
Fuel Capacity	0.5 liters
Oil Capacity	0.25 liters
Starting System	Recoil
Fuel Tank Capacity	0.5 liters
Oil Tank Capacity	0.25 liters
Weight (Powerhead Only)	10.6 lbs
