CS-8000
1. Cylinder, Crankcase, Piston
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
39 + 131051-19830 1
LINK
60L
44 101514-30831 1
COVER, CYLINDER
45 101501-31730 1
COVER, CYLINDER
46 + 101514-30831 1
COVER, CYLINDER
49 + 101578-30830 1
PLUG
47 890623-13930 1
LABEL, NOISE
48 890162-14930 1
LABEL, CAUTION C.B.
- 3 -
