DESCRIPTION
6. Tighten nuts nger tight.
7. Ensure that chain tension adjuster
(F) ts into guide bar hole.
8. Hold the guide bar nose up and turn
the adjuster clockwise until the chain
ts snugly against the underside of
the guide bar.
9. Tighten nuts with the guide bar nose
held up.
10. Pull the chain around the guide bar
by hand. Loosen the adjustment if
you feel tight spots while rotating
chain on the bar by hand.
F
