MAINTENANCE
• 91PX Chain: Use a round 5/32" le
and at le.
• Push le as shown.
• To keep correct position and correct
angle, use a le holder.
30°
Keep this angle
Setting Saw Chain
• Hold the le horizontally.
• Place the depth gauge tool rmly
on guide bar so that depth gauge
protrudes. Then le top of depth
gauge with the at le until at with
top of the depth gauge tool.
• One fth of the le diameter
remains above cutter edge.
90°
1/5
• Be sure to round off the front edge
of the depth gauge.
Depth gauge tool
