ASSEMBLY ES-250
18 X7501182906
© 9/2018 ECHO Inc.
Note: Blower use will eventually loosen pipe connections. Exclusive
positive locking system allows pipes to be tightened. If
loosening occurs, remove lower straight pipe, and install
according to instructions 3 & 4.
Remove Blower Pipes
1. Insert screwdriver (F) into hole
located near lock symbol (G) to
release pipe lock.
Screwdriver tip may stick out opposite side of locking hole.
2. Pull pipe out of fan case.
3. Remove screwdriver.
