GRASS TRIMMER
OPERATOR'S MANUAL
23
MODEL ------------------------------------------ GT-200R
Length-------------------------------------------- 1400 mm (55.1 in.)
Width--------------------------------------------- 310 mm (12.2 in.)
Height -------------------------------------------- 385 mm (15.2 in.)
Weight (dry) w/Cutter Head ------------------- 4.1 kg (9.04 lb.)
Engine Type ------------------------------------- Air cooled, two-stroke, single cylinder gasoline engine
Bore----------------------------------------------- 32.2 mm (1.27 in.)
Stroke--------------------------------------------- 26.0 mm (1.02 in.)
Displacement ------------------------------------ 21.2 cc (1.29 cu. in.)
Exhaust System --------------------------------- Spark Arrestor Muffler
Carburetor --------------------------------------- Zama diaphragm model w/primer
Ignition System --------------------------------- Flywheel magneto, capacitor discharge
Spark Plug --------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Fuel ----------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ------------------------------------ 50 : 1 Power Blend X™ ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345-
FC/
FD, two-stroke, air-cooled engine oil.
Gasoline ------------------------------------------ Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more
than 10% ethyl alcohol or 15% MTBE. Do not use alternative fuels such as
E-20 or E-85.
Oil ------------------------------------------------- Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity ----------------------------- 0.45 lit. (15.2 US fl. oz.)
Starter System ----------------------------------- i30 Automatic Rewind Starter
Clutch -------------------------------------------- Centrifugal Type
Drive Shaft --------------------------------------- 1/4 in. Flex Shaft
Rotating Direction ------------------------------ Clockwise viewed from top
Cutter Head -------------------------------------- Nylon line head (2-line) with .080 Line capacity 203 mm (8 in.)
Handle -------------------------------------------- Left - D-Loop, Right - Grip
Shoulder Harness ------------------------------- Optional P/N 99944200201
Idle Speed (RPM) ------------------------------- 2,750 - 3,250 RPM
Clutch Engagement Speed --------------------- 3,500 - 4,100 RPM
Wide Open Throttle Speed (W.O.T.)
with Nylon Line Head (RPM) ----------------- 7,500 - 8,500 RPM
SPECIFICATIONS
