GRASS TRIMMER
OPERATOR'S MANUAL
9
____ - Trimmer Assembly:
____ - Power Head
____ - Drive Shaft Assembly
____ - Plastic Bag (Co-Pack)
____ - Operator's Manual
____ - Safety Manual
____ - Warranty Card & Limited Warranty
____ - Locking Tool, P/N 89751801131 (head locking tool)
____ - Safety Glasses
____ - Echo Power Blend X
TM
2-stroke oil sample
____ - 12 pcs. 8 in. x .080 Pre-cut Nylon Line
____ - Rapid Loader
TM
2-line Head
____ - Shield Assembly
____ - Line Head Mounting Hardware:
____ - 3/8-24 Locknut
____ - Small Washer
____ - Large Washer
* ___ - Locking Tool, P/N 89751801131 (wrench handle)
* ___ - Wrench 17 x 14.5, P/N X602000031
CONTENTS
The ECHO product you purchased has been partially assembled for your convenience. Due to packaging restrictions,
installation of the plastic debris shield, nylon line head, and positioning of the front handle may be necessary.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
* NOTE
Assembly tools are not supplied with pre-assembled units.
DANGER!
SRM/GT/PAS/SB/PE SAFETY MANUAL
Misuse may result in serious or fatal injuries. You must read, under-
stand, and follow these safety instructions, and the instructions in the
Operator’s Manual, before operating a Model GT Grass Trimmer, SRM
Trimmer-Brushcutter, PAS Pro-Attachment Series Powerhead, SB Split-
Boom Trimmer-Brushcutter, or PE Power Edger.
If you operate a model SB Split-Boom or PAS Pro Attachment Series
multi-attachment unit, you must also read, understand, and follow the
instructions in your PAS Attachment Operator’s Manual.
DANGER!
To locate your nearest Echo dealer, visit our website at www.echo-usa.com, or call 1-800-
432-ECHO (3246). Ask how to obtain a FREE Safety Video. Echo’s supplemental Trimmer
Safety Video provides helpful safety and operating information.
Metal blades are very sharp and can cause severe injuries, even if engine
is off and blades are not moving. Avoid contact with blades. Wear gloves
to protect hands.
X752000040
06/07
X7522270600
ASSEMBLY
Tools Required: Locking Tools (2), Wrench 17 x 14.5 (9/16 in.)
Parts Required: Rapid Loader
TM
Head, Large washer, Small washer,
3/8-24 Locknut, (2) Pre-cut Nylon Line 8 in. x .080 in.,
Plastic Shield Assembly
WARNING
Cut-off knife on debris shield has sharp edges. Avoid contact
when installing or removing line head.
To Next Page
