12
SPECIFICATIONS
MODEL GT-201
Length 1400 mm (55.1 in.)
Width 310 mm (12.2 in.)
Height 385 mm (15.2 in.)
Weight (dry) w/Cutter Head 4.35 kg (9.6 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.268 in.)
Stroke
26.0 mm (1.02 in.)
Displacement 21.2 cc (1.29 cu. in.)
Exhaust Spark Arrestor Muffler w/catalyst
Carburetor Zama diaphragm model w/purge
Ignition System Flywheel magneto, capacitor discharge
Spark Plug NGK BPM-7Y (0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline
89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil 50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity
0.45 lit. (15.2 US fl. oz.)
Recoil Starter System Automatic Recoil Starter
Clutch Centrifugal Type
Drive Shaft 1/4" Flex Shaft
Rotating Direction Clockwise viewed from top
Cutter Head Nylon line head (2-Line) with .080 in. line capacity 6.5 m (20 ft.)
Front Handle Left - D-Loop, Right - Grip
Shoulder Harness Optional P/N 99944200201
Idle Speed (RPM) 2400 - 3200
Wide Open Throttle Speed with
Trimmer Head
6800 - 7500
