HEDGE CLIPPER
OPERATOR'S MANUAL
21
SHARPENING BLADES
Level 3.
Tools required: (2) 10 mm Wrenches, Flat file, Screwdriver
Parts required: None
WARNING DANGER
Hedge Clipper Blades are very sharp. Wear gloves to protect
hands.
1. Disconnect spark plug wire.
2. Remove blade stiffener (see “Blade Stiffener Install/ Remove
instructions”).
3. Slide blades to midpoint cutting position using slots (A) on bottom
of blade. Do not pry against cutting edges.
4. File each edge carefully. Follow the original shape of the blade.
IMPORTANT
If a power grinder is used DO NOT allow blade to over heat.
5. Install blade stiffener (see “Blade Stiffener Install/ Remove instruc-
tions”).
6. Lubricate blades (see “Lubrication instructions”).
IMPORTANT
Blades should only be removed and reinstalled by an Authorized
ECHO Servicing Dealer, otherwise premature wear or internal
damage may occur.
A
A
